iPhone 15 Pro Max Specifications and Features
The iPhone 15 Pro Max is Apple's flagship smartphone from the 2023 iPhone lineup. It features a 6.7-inch LTPO Super Retina XDR OLED display with a 120Hz refresh rate, Apple's A17 Pro 3nm chipset, a titanium frame, a 48MP triple-camera system with 5x optical zoom, and up to 1TB of internal storage.
The phone supports 5G, Wi-Fi 6E, Bluetooth 5.3, NFC, GPS, USB Type-C connectivity, MagSafe wireless charging, and satellite-based emergency features. Its specifications vary slightly by region, particularly the SIM configuration.
iPhone 15 Pro Max Specification Table
| Category | Specification |
|---|---|
| Announced | September 12, 2023 |
| Release Date | September 22, 2023 |
| Status | Available |
| Operating System | iOS 17, upgradable to iOS 18.1 |
| Chipset | Apple A17 Pro (3 nm) |
| CPU | Hexa-core (2×3.78 GHz + 4×2.11 GHz) |
| GPU | Apple GPU, 6-core graphics |
| Display Type | LTPO Super Retina XDR OLED, 120Hz, HDR10, Dolby Vision |
| Display Size | 6.7 inches, 110.2 cm² |
| Screen-to-Body Ratio | ~89.8% |
| Resolution | 1290 × 2796 pixels |
| Aspect Ratio | 19.5:9 |
| Pixel Density | ~460 ppi |
| Display Brightness | 1000 nits typical, 2000 nits HBM |
| Display Protection | Ceramic Shield glass |
| Always-On Display | Yes |
| Dimensions | 159.9 × 76.7 × 8.3 mm |
| Weight | 221 g |
| Build | Glass front, glass back, Grade 5 titanium frame |
| Colors | Black Titanium, White Titanium, Blue Titanium, Natural Titanium |
| SIM — Global | Nano-SIM + eSIM |
| SIM — USA | Dual eSIM with multiple numbers |
| SIM — Hong Kong/China | Dual Nano-SIM, dual standby |
| SIM — India | Nano-SIM + eSIM |
| Network Technology | GSM / CDMA / HSPA / EVDO / LTE / 5G |
| Internal Storage | 256GB / 512GB / 1TB |
| RAM | 8GB |
| Storage Technology | NVMe |
| Card Slot | No |
| Main Camera | Triple camera |
| Main Camera Sensor | 48MP, f/1.8, 24mm wide |
| Telephoto Camera | 12MP, f/2.8, 120mm periscope telephoto |
| Optical Zoom | 5× |
| Ultrawide Camera | 12MP, f/2.2, 13mm, 120° |
| Depth Sensor | TOF 3D LiDAR scanner |
| Main Camera Features | Dual-LED dual-tone flash, HDR, panorama |
| Main Camera Video | Up to 4K at 60fps; 1080p up to 240fps |
| Video Features | 10-bit HDR, Dolby Vision HDR, ProRes, spatial video, stereo sound recording |
| Front Camera | 12MP, f/1.9, 23mm wide |
| Front Camera Features | PDAF, OIS, SL 3D depth/biometrics sensor, HDR, Dolby Vision HDR |
| Front Video | Up to 4K at 60fps |
| Wireless LAN | Wi-Fi 802.11 a/b/g/n/ac/6e, tri-band, hotspot |
| Bluetooth | 5.3, A2DP, LE |
| Positioning | GPS, GLONASS, GALILEO, BDS, QZSS, NavIC |
| NFC | Yes |
| Radio | No |
| USB | USB Type-C 3.2 Gen 2, DisplayPort |
| Loudspeaker | Stereo speakers |
| 3.5mm Headphone Jack | No |
| Battery Type | Li-Ion 4441 mAh, non-removable |
| Wired Charging | PD2.0 |
| Wired Charging Claim | Up to 50% in 30 minutes, advertised |
| Wireless Charging | 15W MagSafe |
| Qi2 Charging | 15W |
| Reverse Wired Charging | 4.5W |
| Sensors | Face ID, accelerometer, gyroscope, proximity, compass, barometer |
| Ultra Wideband | Yes, second-generation chip |
| Emergency Features | Emergency SOS, Messages and Find My via satellite |
Display
The iPhone 15 Pro Max features a 6.7-inch LTPO Super Retina XDR OLED display with a 1290 × 2796-pixel resolution and approximately 460 ppi pixel density. The panel supports a 120Hz refresh rate, HDR10, Dolby Vision, and Always-On functionality.
The display is rated at 1000 nits typical brightness and up to 2000 nits under high-brightness conditions (HBM). Apple also uses Ceramic Shield glass for front protection.
Key Display Specifications
- 6.7-inch OLED panel
- LTPO technology
- 120Hz refresh rate
- 1290 × 2796 resolution
- ~460 ppi
- HDR10
- Dolby Vision
- Always-On display
- Ceramic Shield protection
- 1000 nits typical brightness
- 2000 nits HBM
Performance and A17 Pro Chipset
At the core of the iPhone 15 Pro Max is Apple's A17 Pro chipset, manufactured using a 3nm process. The CPU uses a hexa-core configuration consisting of 2 performance cores and 4 efficiency cores, while graphics are handled by a 6-core Apple GPU.
The phone is available with 8GB RAM and three NVMe storage configurations:
- 256GB
- 512GB
- 1TB
There is no microSD card slot, so users need to choose their required internal storage capacity at purchase.
Camera Specifications
The iPhone 15 Pro Max uses a triple rear-camera system consisting of a 48MP main camera, 12MP periscope telephoto camera, and 12MP ultrawide camera. A LiDAR scanner provides additional depth-sensing capability.
48MP Main Camera
The primary camera uses a 48MP f/1.8 wide sensor with a 24mm equivalent focal length. It includes dual-pixel PDAF and sensor-shift optical image stabilization.
12MP Periscope Telephoto
The dedicated telephoto camera has a 12MP f/2.8 sensor with a 120mm equivalent focal length. It provides 5× optical zoom and combines dual-pixel PDAF with 3D sensor-shift OIS.
12MP Ultrawide
The ultrawide camera features a 12MP f/2.2 sensor, 13mm equivalent focal length and a 120-degree field of view.
LiDAR Scanner
The rear camera system also incorporates a TOF 3D LiDAR scanner, which provides depth information for supported photography and augmented-reality applications.
Camera Video Recording
The iPhone 15 Pro Max supports extensive video-recording capabilities, including:
- 4K at 24/25/30/60fps
- 1080p at 25/30/60/120/240fps
- 10-bit HDR
- Dolby Vision HDR up to 60fps
- ProRes recording
- Spatial/3D video
- Stereo sound recording
The front camera can also record 4K video at up to 60fps and supports gyro-EIS.
Selfie Camera
The front-facing camera is a 12MP f/1.9 wide camera with a 23mm equivalent focal length. It includes PDAF and OIS, while Apple's SL 3D sensor handles depth and biometric functions.
Selfie Camera Features
- 12MP resolution
- f/1.9 aperture
- 23mm equivalent focal length
- PDAF
- OIS
- SL 3D depth/biometric sensor
- HDR
- Dolby Vision HDR
- 4K video up to 60fps
- Gyro-EIS
Battery and Charging
The iPhone 15 Pro Max uses a 4441mAh Li-Ion battery that is not user-removable.
For wired charging, the device supports USB Power Delivery 2.0, with an advertised capability of reaching 50% charge in approximately 30 minutes under compatible conditions.
Wireless charging support includes:
- 15W MagSafe
- 15W Qi2
- 4.5W reverse wired charging
Qi2 support requires the specified iOS 17.2 software update according to the supplied specifications.
Design, Dimensions and Weight
The iPhone 15 Pro Max measures 159.9 × 76.7 × 8.3 mm and weighs 221 grams.
Its construction combines a glass front and glass back with a Grade 5 titanium frame. The available finishes are:
- Black Titanium
- White Titanium
- Blue Titanium
- Natural Titanium
The titanium construction is one of the major design changes associated with the iPhone 15 Pro generation.
Connectivity
The iPhone 15 Pro Max supports a broad range of cellular and wireless communication technologies, including 5G, LTE, Wi-Fi 6E and Bluetooth 5.3.
Its USB Type-C port supports USB 3.2 Gen 2 speeds and DisplayPort functionality.
Connectivity Highlights
- 5G
- GSM/CDMA/HSPA/EVDO/LTE
- Wi-Fi 6E
- Bluetooth 5.3
- NFC
- GPS
- GLONASS
- GALILEO
- BDS
- QZSS
- NavIC
- USB Type-C
- DisplayPort
SIM and Network Support
SIM configuration differs depending on the market.
| Region | SIM Configuration |
|---|---|
| Global | Nano-SIM + eSIM |
| USA | Dual eSIM with multiple numbers |
| Hong Kong / China | Dual Nano-SIM, dual standby |
| India | Nano-SIM + eSIM |
This regional difference is particularly important for buyers importing an iPhone 15 Pro Max from another country.
Sensors and Special Features
The phone includes a comprehensive sensor package:
- Face ID
- Accelerometer
- Gyroscope
- Proximity sensor
- Compass
- Barometer
- Second-generation Ultra Wideband
- SL 3D sensor system
- LiDAR scanner
The device also supports Emergency SOS, Messages via satellite and Find My via satellite where supported.
Frequently Asked Questions
What are the iPhone 15 Pro Max specifications?
The iPhone 15 Pro Max features a 6.7-inch 120Hz LTPO OLED display, Apple A17 Pro 3nm chipset, 8GB RAM, up to 1TB NVMe storage, a 48MP triple rear-camera system, a 12MP selfie camera, 5G connectivity and a 4441mAh battery.
What is the iPhone 15 Pro Max display size?
The iPhone 15 Pro Max has a 6.7-inch LTPO Super Retina XDR OLED display with a 1290 × 2796-pixel resolution and a 120Hz refresh rate.
How much RAM does the iPhone 15 Pro Max have?
The iPhone 15 Pro Max has 8GB of RAM across its listed 256GB, 512GB and 1TB storage configurations.
What chipset does the iPhone 15 Pro Max use?
It uses Apple's A17 Pro chipset, built using a 3nm manufacturing process.
Does the iPhone 15 Pro Max have a 5x optical zoom?
Yes. Its 12MP periscope telephoto camera provides 5× optical zoom.
Does the iPhone 15 Pro Max have a microSD card slot?
No. The iPhone 15 Pro Max does not have a memory-card slot. Storage is available internally in 256GB, 512GB and 1TB configurations.
Does the iPhone 15 Pro Max use USB-C?
Yes. The iPhone 15 Pro Max uses a USB Type-C 3.2 Gen 2 port with DisplayPort support.
Is the iPhone 15 Pro Max dual SIM?
SIM functionality depends on the market. Global and Indian versions support Nano-SIM plus eSIM, the US version uses dual eSIM, while Hong Kong/China models support dual Nano-SIM with dual standby.
How much does the iPhone 15 Pro Max weigh?
The iPhone 15 Pro Max weighs 221 grams.
What are the iPhone 15 Pro Max colors?
The available colors are Black Titanium, White Titanium, Blue Titanium and Natural Titanium.
iPhone 15 Pro Max Key Specifications at a Glance
Display: 6.7-inch 120Hz LTPO OLED
Resolution: 1290 × 2796 pixels
Chipset: Apple A17 Pro (3nm)
RAM: 8GB
Storage: 256GB / 512GB / 1TB
Rear Camera: 48MP + 12MP + 12MP
Optical Zoom: 5×
Front Camera: 12MP
Battery: 4441mAh
Charging: PD2.0, MagSafe 15W, Qi2 15W
Network: 5G
USB: USB Type-C 3.2 Gen 2
Weight: 221g
Frame: Grade 5 titanium
OS: iOS 17, upgradable to iOS 18.1
